Curtain Wall V Groove Cutting Machine Horizontal Four Side V Cutting Machine For Boxes

Brand Name : JM

Model Number : GSFM 1250×4000

Certification : ISO9001 CE

Place of Origin : China

MOQ : 1 set

Price : Negotiate

Payment Terms : T/T

Supply Ability : 10 sets per mouth

Delivery Time : 25-45days

Packaging Details : Waterproof packaging

colour : Blue and white; Customizable

Controller : Touch screen

Temper or not : Yes

Hydraulic or yenot : Yes

Number of Cutterbars : 3 pcs

Cutterbar Properties : Alloy blades or white steel blades

Contact Now

Horizontal four-side v cutting machine for boxes&Curtain wall

Description:

Automatic calculation of internal and external diameters, automatic cycle programming, visual picture editing, bending effect display, tool holder self-lubricating system, intermittent working hydraulic station, etc.The tool holder can be rotated and fixed at 90 °. With the help of high power Y1 motor, the plate can be grooved in the transverse direction without manual rotation.

Name		Parameter	Unit
Max. Width of metal sheet		1250	mm
Max. Length of metal sheet		4000	mm
Max. thickness(Stainless steel)		5	mm
Min. Thickness of metal sheet		0.4	mm
Min.distance of the V from edge		10	mm
Max. cutting speed of X axis		120	m/min
Max .return speed of the X axis		120	m/min
Max.distance of Y axis		1250	mm
Resolution in Y1 axis		0.001	mm
Repeated positioning accuracy		±0.01	mm
Resolution in z axis		0.001	mm
Repeated positioning accuracy		±0.01	mm
Motor power	X axis	5.5	kW
	Y1	3.0
	Y2.U,Z axis	1.0
Overall dimension	Length	5900	mm
	Width	2580
	Height	1550

Application:

Architectural decoration, bathroom, kitchen utensils, door industry, elevator equipment, aluminum curtain wall, advertising signs, equipment covers, automobile manufacturing, mechanical equipment, electrical equipment, precision parts, hardware products, aluminum and copper products, etc.
