Intelligent Solution V Groove Cutting Machine For Door Fully Automatic Four Sided

Brand Name : JM

Model Number : GSFM

Certification : ISO9001,CE

Place of Origin : Wuxi,China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T

Supply Ability : 25 sets per mouth

Delivery Time : 15-45 days

Packaging Details : Waterproof packaging

Controller : Touch screen

Number of Cutterbars : 3 pcs

Colour : Blue and white; Customizable

Temper or not : Yes

Drag chain : Totally enclosed

Controller position : On the gantry; Customizable to separate

Contact Now

Intelligent Solution for Door Industry Processing: Fully Automatic Four Sided V Groove Cutting Machine

The base (a) and crossbeam (c) of GSFM v grooving machine are designed with frame structure, and the worktable is made of low-alloy high-strength structural steel. The machine tool is rigid and durable as a whole. The machine tool processing process shall be strictly followed, and electric furnace tempering shall be adopted to eliminate welding stress and reduce equipment deformation. Ensure excellent painting effect through sand blasting. The frame is formed by the imported CNC stereo machining center through one-time clamping processing, ensuring the parallelism and perpendicularity of each mounting surface.

Keep all functions of the standard model
Automatic calculation of internal and external diameters, automatic cycle programming, visual picture editing, bending effect display, tool holder self-lubricating system, intermittent working hydraulic station, etc.

One-time forming of workpiece
The workpiece no longer needs to be shifted manually, which greatly improves the dimensional accuracy, saves labor costs, saves time costs and improves production efficiency.

No.	Name		Parameter	Unit
1	Max. Width of metal sheet		1500	mm
2	Max. Length of metal sheet		4000	mm
3	Max. thickness(Stainless steel)		5	mm
4	Min. Thickness of metal sheet		0.4	mm
5	Min.distance of the V from edge		12	mm
6	Max. cutting speed of X axis		120	m/min
7	Max .return speed of X axis		120	m/min
8	Max.distance of Y axis		1250	mm
9	Resolution in Y axis		0.001	mm
10	Repeated positioning accuracy		±0.01	mm
11	Resolution in z axis		0.001	mm
12	Repeated positioning accuracy		±0.01	mm
13	Motor power	X axis	5.5	kW
		U	3.0
		Y1,Y2,Z axis	1.0
14	Overall dimension	Length	5980	mm
		Width	2420
		Height	1600
